Lift Tension Deadend for ADSS

Availability:
Quantity:
Inquire Add to Basket

Lift Tension Deadend for ADSS:
Material: aluminum-clad steel wire

-For tension the adss cables to the pole.
WU P/N Supported Cable Diameters Length(L) Color Mark
Min(in) Max(in) Min(mm) Max(mm) in M
TYPE 1 0.351 0.360 8.9 9.1 24 0.61 Black
TYPE2 0.375 0.414 9.5 10.5 28 0.71 Red
TYPE3 0.415 0.459 10.6 11.6 31 0.79 Orange
TYPE 4 0.460 0.505 11.7 12.8 33 0.84 Green
TYPE 5 0.507 0.555 12.9 14.1 37 0.94 Pink
TYPE 6 0.559 0.614 14.2 15.6 42 1.07 Yellow
TYPE7 0.616 0.680 15.7 17.3 45 1.14 Blue
TYPE8 0.685 0.751 17.4 19.1 49 1.24 Brown
