Used to secure figure 8 cable to poles. Clamp plates and J Hooks are extruded from Aluminum. J hooks are designed to dig into poles when installed, to prevent movement during tensioning of cable. Eliminates the need to pre-strip messenger wire. Bolt size accommodated is 5/8". "> Brief:TANGENT SUPPORT CLAMP .109" TO .134" FOR 5/8" BOLT Used to secure figure 8 cable to poles. Clamp plates and J Hooks are extruded from Aluminum. J hooks are designed to dig into poles when installed, to prevent movement during tensioning of cable. Eliminates the need to pre-strip messenger wire. Bolt size accommodated is 5/8".
• All components are mechanically galvanized to meet ASTM Specification B695, Class 50, Type 1. • Manufactured in the United States. • Bolt and nut are formed from Grade 2 Steel. • Bolt and nut are hot dip galvanized to meet ASTM Specification A153, Class B3. • Bolt is 3⁄8" diameter for additional strength. • Attaches to strand sizes ranging from 1⁄4" (6.6M) to 3⁄8" (10M). "> Brief:• Used in drop cable installations as an attachment to the strand for either accepting the bail of Drop Wire Clamps, or for wrapping the support wire of drop cable. • Consists of high strength Aluminum jaws, and a specially shaped bolt with square nut. • Jaws are extruded from 6063-T6 Aluminum. • The jaws are stamped from AISI 1018 Cold Rolled Steel. The stud is formed from Grade 5 hardened Steel. The nuts and washers are formed from Grade 2 Steel. • All components are mechanically galvanized to meet ASTM Specification B695, Class 50, Type 1. • Manufactured in the United States. • Supplied with two 3⁄8" x 1" Hex Bolts. • All components are mechanically galvanized to meet ASTM Specification B695, Class 50, Type 1. • Manufactured in the United States. • Bolt and nut are formed from Grade 2 Steel. • Bolt and nut are hot dip galvanized to meet ASTM Specification A153, Class B3. • Bolt is 3⁄8" diameter for additional strength. • Attaches to strand sizes ranging from 1⁄4" (6.6M) to 3⁄8" (10M).
Consists of two plates,and two 1/2"-13 track bolts with attached square nuts. Plates are 1-13/16" wide and 5-3/4" long. The center hole accepts 5/8" or 3/4" thru bolt. Hot dip galvanized to meet ASTM Specification A153. "> Brief:Used to attach strand to straight line poles. Accepts 1/4" (6.6M) to 7/16" (16M) strand. Consists of two plates,and two 1/2"-13 track bolts with attached square nuts. Plates are 1-13/16" wide and 5-3/4" long. The center hole accepts 5/8" or 3/4" thru bolt. Hot dip galvanized to meet ASTM Specification A153.
